NVME/SATA M.2 to USB 3.1 Gen 2 SSD Reader for M Key & B+M Key, AC-SP02
$13.99 $14.99


M.2 to USB 3.2 Adapter 10Gbps Support M.2 NVMe SSD and M.2 SATA SSD


Kill Two Birds with One Stone
We use RTL9210B chip, which can support NVMe (PCIe 3.0 X2, 10Gbps) and SATA III (6Gbps) protocols at the same time, that is, it can support M.2 NVMe SSD and M.2 SATA (NGFF) SSD. Let you spend a share of money to get an adapter that can read two kinds of SSDs


Length of SSD


Support NVMe and SATA protocols
M.2 SSDs of nvme and SATA protocols can be used on this adapter.
Support M.2 NVMe SSD and M.2 SATA (NGFF)
SSDs with length of 2230 / 2242 / 2260 / 2280 / 22110 are supported
M.2 SSDs of all lengths can be supported, but the 2230 / 22110 SSDs of two lengths can only be tied tightly with free rubber bands and cannot be fixed with silica gel.


10Gbps


M.2 SATA SSD is also fast
The test speed of M. 2 SATA is 450M / s.
- The maximum speed of NGFF is 6gbps, which is actually affected by SSD and computer.
Amazing Transmission Speed
1029M/s
Using M.2 NVMe SSD, the test speed is up to 1029m / s, and the transmission of a movie is completed in 1 second
- The maximum speed of M.2 NVMe SSD is 20Gbps, which is actually affected by SSD and computer
No Screws, Easy Installation
|
|
|
|
---|---|---|---|
Step 1Plug the SSD into the adapter interface |
Step 2Clamp the silicone plug and press the silicone plug into the bayonet |
Step 3Attach the aluminum alloy heat sink to the SSD |
Step 4Put on a rubber band for reinforcement |
Product Name | M.2 to USB Adapter |
Model | AC-SP02 |
Function | Convert M.2 NVMe SSD and M.2 SATA SSD into USB interface |
Master Chip | RTL9210B |
Transmission Speed | M.2 NVMe:900M/s,NGFF:354M/s |


USB-IF standard
USB3.2 Gen2=USB3.1 Gen2,Product transfer rate is up to 10Gbps,Extreme transmission speed 1250MB/s,Marketing name: SuperSpeed USB 10Gbps,
USB3.2 Gen1=USB3.1 Gen1=USB3.0,Product transfer rate is up to 5Gbps,Extreme transmission speed 625MB/s,Marketing name: SuperSpeed USB.
